Product Size
YDXPin
17mm PinIP Rating
IP66Rated Current
≤7Rated Voltage
250Product Series
YDXWiring Type
WeldingInterface Type
ThreadedMating Cycles
500 timesComplies with product certification:
GB3836.1-2010 "Explosive Atmosphere Part 1: General Requirements for Equipment"; GB3836.2-2010 "Explosive Atmosphere Part 2: Equipment Protected by Flameproof Enclosures 'd'"System certification:
Explosion-proof grade - Ex db ⅡC T6Gb; applicable to Areas 1 and 2 with ⅡA, ⅡB, ⅡC class explosive gases of T6 temperature group
